Hydraulic Dilling Machine Hydraulic Dilling Machine

Model H-2000 Model H-7150
Max.Drilling Capacity Ø20mm Max.Drilling Capacity Ø25mm
Spindle Taper MT3 Spindle Taper ER32 / MT3
Spindle Travel 130mm Spindle Travel 150mm
Spindle Speed 3S 470.790.1280 Spindle Speed 3S 500.1000.1500

Swing Ø460mm Swing 460mm
Table Diameter 600*800mm Table Diameter 600*800mm
Column Diameter Ø92mm Column Diameter Ø102mm
Distance From Spindle To Table 100-700mm Distance From Spindle To Table 350-700mm
Motor HP 2HP Motor HP 2HP
Hydraulic Power kg/cm 2 20kg/cm 2 Hydraulic Power kg/cm 2 20kg/cm 2
Overall Height 1900mm Overall Height 2100mm

Weight 300kg Weight 600kg

Model H-2500 Model H-9150
Max.Drilling Capacity Ø25mm Max.Drilling Capacity Ø35mm
Spindle Taper MT3 Spindle Taper ER40 / MT4

Spindle Travel 130mm Spindle Travel 150mm
Spindle Speed 3S 640.1410.1620 Spindle Speed 3S 100.200.300
Swing Ø460mm Variable Speed 500-2000mm
Table Diameter 600*800mm Swing 520mm
Column Diameter Ø102mm Table Diameter 600*800mm
Distance From Spindle To Table 100-700mm Column Diameter Ø115mm
Motor HP 2HP Distance From Spindle To Table 350-700mm

Hydraulic Power kg/cm 2 20kg/cm 2 Motor HP 3HP
Overall Height 1900mm Hydraulic Power kg/cm 2 20kg/cm 2
Weight 380kg Overall Height 2100mm
Weight 700kg
