Page 11 - Automatic Drilling Machine - Liang Lih Machine Co., Ltd.

Pneumatic Peck Feed Drilling Machine Pneumatic Peck Feed Drilling Machine

Model P-50-100A Model P-60-150
Max.Drilling Capacity Ø10mm Max.Drilling Capacity 16mm
Spindle Taper JT6 Spindle Taper ØMT2
Spindle Travel 100mm Spindle Travel 150mm
Stabilizer Travel 60mm Stabilizer Travel 60mm

Spindle Speed 1000.2000.3000 Spindle Speed 1000.1500.2000
Number Of Speed 3 Number Of Speed 3
Swing 360mm Swing 460mm
Column Diameter Ø80mm Table Diameter 600*800mm
Base Diameter Ø320mm Column Diameter Ø102mm
Table Diameter 330*510mm Distance From Spindle To Table 100-700mm
Distance From Spindle To Table 400mm Motor HP 2HP

Distance From Spindle To Base 600mm Pneumatic Power kg/cm 2 5kg/cm 2
Motor HP 1HP Overall Height 1800mm
Pneumatic Power kg/cm 2 5kg/cm 2 Weight 350kg
Overall Height 1350mm
Weight 100kg

Model P-50-100
Max.Drilling Capacity 10mm
Spindle Taper ØJT6
Spindle Travel 100mm
Stabilizer Travel 60mm

Spindle Speed 1000.2000.3000
Number Of Speed 3
Swing Ø360mm
Table Diameter 450*600mm
Column Diameter Ø80mm
Distance From Spindle To Table 100-400mm
Motor HP 1HP
Pneumatic Power kg/cm 2 5kg/cm 2
Overall Height 1600mm

Weight 230kg

9 10
